HTD Series Electric Screw Tower series Features:
Electro-Mechanical Multi-Screw Motor Driven Mast
Fully Internal Lift Mechanism including zero exposure of moving parts
ALL Models include Auto-limit switches to automatically control max extended and retracted elevations
All Models include Removable Wired Remote Control or Built-in Control Panel
Numerous Control Accessory options such as wireless remotes, remote mount control panels, lift height='auto' rea LCD displays,
Supports Manual Crank for emergency no power scenarios with removable handle
Standard Models offering Extended Lift to Approx. 15ft, 20ft, 25ft, 30ft, 35ft, 45ft, 50ft to greater while offering low profile Nested height='auto' reas (retracted)
Light Weight Towers Systems with payloads averaging 60 to over 100 lbs. without guy wire
Convenient Operation with Precise Elevation Position Control at any extended height='auto' rea
Ideal for Rapid Response to Long-Term Deployments
Unfailing System Operation even in Extreme Weather like Freezing or the hottest summer days
Strong Resistance to Sand, Dust or other High Particle Environments
Excellent Weatherproof Design w/Anodized or Coated Finish for added protection against acid rain and corrosion
Superb Construction primarily made from Heat Treated, Hardened Aluminum Alloys
Built to Rugged Standards such as MIL-STD-810
Includes Base Mounting Plate and Top Mount Plates by Default
Default Colors of White, Black, Silver with alternate color options
Power Input options for 12V, 24V, 48V DC or utility power like AC 110V or 220V etc.
Numerous Optional accessories including upper brackets, Nycoil, Nycoil baskets, etc.
GeMinG series Elton-Mechanical Screw Mast are an ideal solution for demanding applications be it military, law enforcement, border security or homeland security to commercial, education, transit, industrial or energy projects and more. Perfect for command vans and trucks to high quality surveillance or communication trailers the units can support an almost unlimited array of equipment be it lighting, video, sensory, wireless and more. In fact, the GeMinG series series Electric Mechanical Screw Mast can provide easier adaptability than alternative types like pneumatics as the GeMinG series series requires no additional pump systems and allows for common DC voltage inputs like 12v, 24v or 48V while AC options are also offered. Even more the units provide superb precision allowing mast to be elevated to any point within its range including for long-term deployments with the push of a button where as other styles like locking pneumatics will require management of the locking mechanism per section.
Additionally, the GeMinG series likewise boast quality materials such as utilizing primarily heat-treated hardened aluminum alloy for its construction giving increased strength yet making it light weight compared to its payload support. The GeMinG series series telescoping tower is perfectly suited for critical demands as the GeMinG series series can operate unhindered in extreme weather such as freezing temperatures to extreme heat beyond the limits where pneumatic mast is known to fail. They also by default include a manual crank support with removable handle ideal for emergency situations where no power is available. GeMinG series Systems include a removable wired remote control by default while other options such as wireless remote, free mountable remote-control panel to Height Counter LCD Display accessories are just some of the possibilities.
GeMinG series units are supplied with a sturdy base mounting plate including large diameter pre-drilled holes allowing for easy installation to a solid structure bearing surface via hea
nal accessories like guy wire adapter plates, base tube support brackets, custom Nycoil and cabling, custom top plates, device arms etc. all are available. HTD Series Experts are available to assist you with sourcing the best telescopic mast alone to complete tower packages with Lighting, Visible and Thermal Video Surveillance PTZ Cameras, Radar, Audio like Public Address Speakers or all sorts of Wireless Communications and beyond.
