The HTW76 series is GeMinG's new linear actuator designed for heavy-duty applications developed in harsh environments that require high lifting capacity and holding power. HTW76 provides GeMinG's well-known quality to ensure a long-life maintenance-free product. Complex applications require actuators with the same requirements. It is a very powerful actuator designed for various applications, such as agricultural machinery, construction machinery and industrial machinery. Due to its large capacity, well-designed and IP69-level protection, Chromium actuators are very suitable for agricultural, construction and industrial machinery and equipment. The biggest advantage; the stroke, installation length and product durability can be adjusted. The whole product all metal material does not contain any plastic parts...


Product Features


Motor type: permanent magnet DC motor
Voltage: 12V DC, 24V DC, 36V DC, 48V DC
Maximum load: 16,000N/pull/push
The fastest speed at full load: 89 mm / s (load 700N)
The slowest speed at full load: 3.4mm/s (load 16,000N)
Stroke: 50~900mm
Minimum size: stroke + 200mm (limited to 500mm stroke or less)
Minimum size: stroke + 250mm (over 500mm stroke or more)
Colour: Black
IP rating: IP69K
Operating temperature range: -45°C~+75°C
Full performance operating temperature range: +5°C~+45°C
Higher duty cycle (25%)
Other options: Hall sensor, potentiometer, passive signal
High-strength metal zinc alloy housing protects motors and gears
Limit switch (built-in: not adjustable) (external-adjustable)
